DEHNcare ArcFit HLP 63

  • All-round protection with arc flash protection class APC 2 – PPE 4 as per NFPA 70E
  • Even more safety for demanding work – APC 2 also with increased arc energy of 630 kJ (Warc or WLBP)
  • Environmentally friendly – washable up to 60°
  • Certified according to PPE regulation (EU) 2016/425

Details

lorem ipsum

Arc-fault-tested protective jacket

7 Products

Part No. 787370 APJ 63C S

GTIN 4013364512467, Customs tariff No. (EU): 62033911, Gross weight: 1.67 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 48 (S)

Product 787370 was added to Notepad.

Go to Notepad

Product 787370 was added to the cart.

Go to Web-Shop

Part No. 787371 APJ 63C M

GTIN 4013364512337, Customs tariff No. (EU): 62033911, Gross weight: 1.74 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 50/52 (M)

Product 787371 was added to Notepad.

Go to Notepad

Product 787371 was added to the cart.

Go to Web-Shop

Part No. 787372 APJ 63C L

GTIN 4013364512344, Customs tariff No. (EU): 62033911, Gross weight: 1.81 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 52/54 (L)

Product 787372 was added to Notepad.

Go to Notepad

Product 787372 was added to the cart.

Go to Web-Shop

Part No. 787373 APJ 63C XL

GTIN 4013364512351, Customs tariff No. (EU): 62033911, Gross weight: 1.88 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 56/58 (XL)

Product 787373 was added to Notepad.

Go to Notepad

Product 787373 was added to the cart.

Go to Web-Shop

Part No. 787374 APJ 63C 2XL

GTIN 4013364512368, Customs tariff No. (EU): 62033911, Gross weight: 2.04 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 58/60 (2XL)

Product 787374 was added to Notepad.

Go to Notepad

Product 787374 was added to the cart.

Go to Web-Shop

Part No. 787375 APJ 63C 3XL

GTIN 4013364512375, Customs tariff No. (EU): 62033911, Gross weight: 2.11 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 62/64 (3XL)

Product 787375 was added to Notepad.

Go to Notepad

Product 787375 was added to the cart.

Go to Web-Shop

Part No. 787376 APJ 63C 4XL

GTIN 4013364512382, Customs tariff No. (EU): 62033911, Gross weight: 2.18 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 64/66 (4XL)

Product 787376 was added to Notepad.

Go to Notepad

Product 787376 was added to the cart.

Go to Web-Shop

Arc-fault-tested protective trousers (bib overall as over-trousers)

7 Products

Part No. 787380 APD 63C S

GTIN 4013364512399, Customs tariff No. (EU): 62034911, Gross weight: 2.20 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 48 (S)

Product 787380 was added to Notepad.

Go to Notepad

Product 787380 was added to the cart.

Go to Web-Shop

Part No. 787381 APD 63C M

GTIN 4013364512405, Customs tariff No. (EU): 62034911, Gross weight: 2.26 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 50/52 (M)

Product 787381 was added to Notepad.

Go to Notepad

Product 787381 was added to the cart.

Go to Web-Shop

Part No. 787382 APD 63C L

GTIN 4013364512412, Customs tariff No. (EU): 62034911, Gross weight: 2.31 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 52/54 (L)

Product 787382 was added to Notepad.

Go to Notepad

Product 787382 was added to the cart.

Go to Web-Shop

Part No. 787383 APD 63C XL

GTIN 4013364512429, Customs tariff No. (EU): 62034911, Gross weight: 2.37 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 56/58 (XL)

Product 787383 was added to Notepad.

Go to Notepad

Product 787383 was added to the cart.

Go to Web-Shop

Part No. 787384 APD 63C 2XL

GTIN 4013364512436, Customs tariff No. (EU): 62034911, Gross weight: 2.42 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 58/60 (2XL)

Product 787384 was added to Notepad.

Go to Notepad

Product 787384 was added to the cart.

Go to Web-Shop

Part No. 787385 APD 63C 3XL

GTIN 4013364512443, Customs tariff No. (EU): 62034911, Gross weight: 2.48 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 62/64 (3XL)

Product 787385 was added to Notepad.

Go to Notepad

Product 787385 was added to the cart.

Go to Web-Shop

Part No. 787386 APD 63C 4XL

GTIN 4013364512450, Customs tariff No. (EU): 62034911, Gross weight: 2.53 kg, PU: 1.00 pc(s)

Images

Additional information

Certificates



Technical data

Arc fault protection class (box test 7 kA / 0.5 s – single-pole) APC 2
Arc energy (Warc or WLBP ) 320 kJ
Extended electric arc energy (Warc or WLBP) (based on box test) 630 kJ
Arc Rating – ATPV (Open Arc) 63 cal / cm²
Arc Rating – ELIM (Open Arc) 58 cal / cm²
PPE category (NFPA 70E) PPE 4
Outer fabric weight per unit area 225 g / m²
Lining / non-woven material weight per unit area 430 g / m²
Colour navy blue
Zipper red
Size (international) 64/66 (4XL)

Product 787386 was added to Notepad.

Go to Notepad

Product 787386 was added to the cart.

Go to Web-Shop
